SX-EQ7B
Soundmax
| Graphic center frequencies | 50Hz, 125Hz, 315Hz, 750Hz, 2.2KHz, 6KHz, 12KHz |
| Boost / cut | 12dB |
| S/ Nratio | 95dB |
| Frequency response | 10Hz-50KHz +/- 1 dB |
| Maximum output voltage | 7V |
| T.H.D | 0.05% |
| Input sensitivity | 50mV - 3V |
| Head room | 20dB |
| Input impedance | 20K ohms |
| Output impedance | 2K ohms |
| Stereo separation | 82dB/1KHz |
| Operating voltage | 11V-15V Negative Ground |
| Size | 184L×97.5W×30H(MM) or L7.24" × W3.83"xH1.18 |
